CRAFTLANDER 26' X 108" HIGHTOP FRAME
This is a 26' x 108" High Top Craftlander Aluminum Canopy Frame and can be used with any Craftlander lift with a 108" inside width and comes with the complete canopy frame and standard 48" canopy legs.
If your boat has a tower or tall canopy as part of its design you should seriously consider the 'tower end bow' canopy option. This specially designed end bow for the Craftlander high-top canopy frame is welded specifically to allow watercraft with large towers like wakeboard boats, boats with ski towers, and pontoon boats to enter and exit the lift with ease. The tower end bow's lower frame tube has been raised and welded well above the rest of the canopy frames lower frame tube. This gives you much more room coming in and out of the lift. Since your canopy legs don't have to be raised as high to enter or exit you can tuck your towered boat up into the high-top frame even more for far superior coverage when the boat is being stored.
If you order a new canopy cover to match the frame with a 'tower end' your cover will come with 'zippered ends'. This means the rear face of the cover at the entrance to the lift will have two verticle zippers to 'zip-up' the rear panel when entering and exiting the lift. In conjunction with the tower end bow, this solves most height issues when storing your towered watercraft while maximizing boat coverage when the boat is being stored on the lift.
If the height of the frame is still an issue then we then recommend upgrading to 66" XL canopy legs which will give you another 18" of height with which to get the lift in and out of.
<div style="background:#eee;border:1px solid #ccc;padding:5px 10px;"><strong>SHIPPING NOTE</strong>: Our website calculates live freight shipping costs. With some of our larger products, we can provide <strong>better shipping rates</strong> by running a custom shipping request, specifically when multiple products are combined into one shipment. If you would like to get a custom shipping quote, please sign in or create an account, add the products you desire to your cart, and on the cart page, click the "Request a Quote" link, and we will run it manually to see if we can get a better rate. You can also do this if you want to <strong>pick up products</strong> from our Plainwell, Michigan location. Not available for all product lines.</div>
SHIPPING NOTE: Our website calculates live freight shipping costs. With some of our larger products, we can provide better shipping rates by running a custom shipping request, specifically when multiple products are combined into one shipment. If you would like to get a custom shipping quote, please sign in or create an account, add the products you desire to your cart, and on the cart page, click the "Request a Quote" link, and we will run it manually to see if we can get a better rate. You can also do this if you want to pick up products from our Plainwell, Michigan location. Not available for all product lines.
KEY FEATURES
- Fits Craftlander Lifts with 108" inside width
- Aluminum Construction
- 'Tower End' Optional
- 66" XL Canopy Leg Optional
INCLUDES
- Side Frames
- Hoop Bundle
- Canopy Support Braces
- Hardware Box
- 48" Standard Leg Set (can upgrade to 66" XL canopy legs)
Canopy Support Leg Note: This canopy frame and its support legs are designed for installation on an existing Craftlander boat lift. The included support leg bundles are pre-drilled for height adjustment. Each leg bundle contains three non-winch column support legs and one winch column support leg. The winch column support leg is intentionally designed to be slightly shorter than the non-winch column support legs. Additionally, it features a machined slot to allow for the boat lift winch to remain in place during installation, eliminating the need for its removal.
FRAME KIT DOES NOT INCLUDE A CANOPY COVER. Covers are available in several materials and colors designed to fit this frame and can be added under the "canopy cover options" drop-down menu on this product page.
ADDITIONAL INFORMATION
- When the carrier picks up the items then tracking information will be sent via email.
- For estimated shipping charges add the items to your cart and enter your zip code into the shipping calculator on the cart page.
