SHOREMASTER LARGE POLY PIPE BRACKET - GRAY
The Large Poly Pipe Bracket attaches to the recessed exterior channel of an existing ShoreMaster PolyDock and the bow end of ShorePort Sections. When attached the Large Poly Bracket is used to anchor the section into location with the use of a applicable pipe/post (pipe not included).The collar installed on each Poly Pipe Bracket allows your the floating section to adjust when water levels fluctuate.
Includes:
- 1-Large pipe bracket
- 1-21" Connector with hardware
ShoreMaster’s pile guides are designed to easily accept poles from 2” to 4-1/2” in diameter. The appropriate diameter, quantity and sunken depth of pole will depend on your weather conditions and water depth. Poles may be constructed from a variety of materials, including galvanized steel, wood, and concrete. Oftentimes, when galvanized steel piping is used, a PVC covering will be placed over the top to improve the appearance. Most poles for residential applications may be sunk by hand using a sledgehammer. Auger tips for the pipe are also available to auger the pipe into the lake bottom. The wear plate will come standard with a 2-7/8” opening for 2-3/8” outside diameter pipe. The opening may be cut to any size up to 5” in diameter (to accommodate a pole up to 4-1/2“ outside diameter)
Large Poly Pipe Brackets in typical configurations should be placed approximately every 20' and they are also recommended at the end sections of a system.
The use of the Large Poly Pipe Bracket is recommended when mounting the ShorePort perpendicular to a freestanding dock, floating dock or seawall. When placing the RhinoPort perpendicular to a freestanding dock, floating dock, or seawall the use of two Large Poly Pipe brackets is required. Each bracket should be located at the front outside corners of the platform. For the best results when using any of the offered Poly Pipe Brackets, it is recommended that the ShorePort Universal Stand-Off Plate Assembly (sold separately) is also used. The Universal Stand-Off Plates are used as a connection bracket that mounts directly to your dock or seawall and also secures to the top of the 2" pipe used for anchoring. This creates a rigid connection between the pipe and your dock or seawall.
If you have questions or require assistance with proper hardware configurations please contact us.
ADDITIONAL INFORMATION
- Item may ship direct from the manufacturer.
- Tracking information will be provided via email when the shipper catalogs the pick-up.
- You can estimate your shipping charges by adding the item to your cart and entering your zip code into the shipping calculator.
