The All-New PRO Pontoon Port by Wave Armor

Experience the convenience and durability of the Pontoon Port by Wave Armor—a floating, drive-on docking system designed specifically for Pontoon and Tritoon boats up to 23–25 feet in length. Built with Wave Armor’s signature rugged rotomolded shell and fully filled with marine-grade EPS foam, this system delivers long-lasting, maintenance-free performance in all conditions.

The Pontoon Port can be seamlessly integrated with a Wave Armor floating dock, other floating dock systems, permanent docks, or set up as a freestanding unit using the appropriate anchoring hardware. Whether you're upgrading your lakefront setup or building a new one from scratch, this versatile solution adapts to your needs.

PONTOON PORT KEY FEATURES

• Designed for Pontoons & Tritoons up to 23–25′
• Overall Dimensions: 27′ L × adjustable width
• Deck Height: 15″ (not including bow stop)
• Weight Capacity: 4,800 lbs
• Weight: 1,300 lbs
• Optional buoyancy boosters available to increase capacity
• Not recommended for Manitou® Pontoons

The Pontoon Port by Wave Armor is engineered with performance and usability in mind, making docking your pontoon or tritoon boat a smooth and stress-free experience. Its heavy-duty, flared entrance features self-centering guides that help position your boat perfectly every time, ensuring a seamless transition from water to dock. An adjustable bow stop allows for a customized fit, giving you added security and flexibility to accommodate different boat lengths within the supported range.

To enhance both protection and ease of use, the Pontoon Port is equipped with specially designed rollers that offer cushioned support while guiding your boat into perfect alignment. The strategic axle pocket heights are engineered to minimize drag, reducing strain during both loading and unloading. All of this is built into a platform constructed from a durable rotomolded polyethylene shell, fully filled with marine-grade EPS foam, delivering unmatched strength, stability, and long-term, maintenance-free performance.

CONNECTION & ANCHORING OPTIONS

Front Mount Direct Connect to Wave Dock Kit - Designed specifically for the pontoon port and pro port series, this one-piece receiving bracket slides directly into the H-Beam channel of the Wave Armor dock section, making it the easiest and fastest mounting connection on the market. Allows for hinge like movement during wave action. To install the slide connectors, simply insert them into the dock channel. Ensure that the threaded inserts are facing upward during installation. Applying a small amount of lubricant to the connectors will help them slide into place more easily. Requires 2 kits per installation.

Front Mount to Floating Dock Kit - This heavy-duty poly bracket is designed specifically for the pontoon port and pro port series creating a receiver that attaches to the galvanized C-Channel on one side and connected with a pin to the port front mounting pocket. Designed for securing to any floating dock structure. The C-channels must be secured using a minimum of four mounting holes located on the back side of each channel. Please note that mounting hardware is not included, as attachment methods can vary based on your specific dock type and configuration. Be sure to choose hardware that provides a strong, secure fit for your installation. Requires 2 kits per installation. Available in 2 sizes: 19.75" C-Channel or 25.75" C-Channel.

Pylon Hoop Attachment Kits –  You can anchor the Pontoon Port using pilings or posts driven into the lake bottom. These can be either existing dock pilings or newly installed steel or aluminum posts. The heavy-duty rotomolded pylon hoop accommodates pylons up to 8", 10", or 12" in diameter, and thanks to its thoughtful design, it attaches easily to both new and existing pilings.

Pontoon Port Pipe Anchoring Kit – Post Brackets are also available for smaller-diameter steel or aluminum posts driven into the lakebed. This anchoring system allows the Pontoon Port to be installed as a freestanding unit using a pipe-mount configuration or positioned inside a boat slip without requiring direct dock attachment. It can also be mounted to a seawall when paired with the appropriate brackets. All components are designed to connect securely over the molded-in horseshoe-shaped pockets along the Pontoon Port’s perimeter. Available in 2" and 3" pipe sizes.

Buoyancy Booster Pontoon - Designed specifically for the pontoon port this buoyancy booster provides an extra 250 lbs. of floatation per booster. The booster can be installed along the perimeter of the pontoon port in multiple molded-in underside pockets, even after full port installation is completed. Set of 2 included. No tools or hardware needed for installation.

ADDITIONAL INFORMATION

This product requires specialized freight delivery. On-site fork lift for and/or loading dock strongly recommended for delivery and off-loading. Local pickup from our location available with appointment. Some product assembly is required.
