LS4 4' x 12' Aluminum Dock Frame with Anodized Stringers - No Decking
Discover the new ultimate residential dock section! The LS4 is strong, stable, easy to configure, and offers one of the best values on the market. Its full 4" tall anodized aluminum box frame construction provides nearly twice the amount of frame material compared to common anodized 4'x12' dock sections with F-channel stringer construction. This results in a more rigid section and enhanced stability.
Key Features
- 4" Fluted Anodized Tubular Stringers
- Inside Width (Decking): 48" Wide x 12' Long
- Overall Width: 51" Wide x 12' 5" Long
The LS4 Frame does not include decking but is compatible with various decking options. It features an inside width of 48" with 16" on-center front-to-back welded tube supports. Additionally, a welded-in 1" lip runs down both sides inside the sections to secure the decking. The frames are compatible with our 48" wide Titan and ThruFlow decking options or any decking option that uses 16" centers.
LS4 sections have a modular design, allowing leg supports to be added at any of the four corners. This, combined with versatile section connectors that can be used on any side, provides countless options for dock layout configurations. The sections also feature an accessory track system, enabling quick and easy installation or removal of accessories without drilling holes into the section.
Each section includes two support pockets, four pocket braces, two base pads, and two section connectors. The support pockets are compatible with our 2" OD aluminum dock post options for extension legs (dock posts sold separately).
Included
- Dock Frame
- (2) Leg Pockets
- (4) Leg Pocket Braces
- (2) Section-to-Section Connectors
- (2) 8" x 12" Base Pads
- (4) Plastic Corner Trim Caps
Additional Information
- Ships via LTL Freight or can be picked up at our Plainwell facility once an order has been placed and confirmed.
- Compatible with 48" wide ThruFlow, Titan Deck, SureStep, and Sunwalk decking panels.
